Cintiq Pro 32

Cintiq Pro 32



Product Type : Creative Pen Display



Model number : DTH3220



Size : 854 x 506 x 53.25 mm (33.62 x 19.92 x 2.1 inch)



Weight : 13 kg (28.66 lbs) without optional stand



Screen Size (Measured Diagonally) : 80 cm / 31.5 inch



Technology : IPS UHD high brightness panel



Displayable Colors (maximum) : 1.07 billion colors (10 bits color)



Aspect Ratio : 16:9



Viewing Angle : Range Up to 64° from vertical (26° from horizontal, up to 90°)



Contrast Ratio : 750:1 (min) / 1000:1 (Typ)



Brightness : 310cd/m2 (min, duty 100%)



Response Rate : 8 ms



Active Area : 697 X 392 mm (27.44 X 15.43 inch)



Color Gamut : 98% Adobe RGB



Industry Standard Pre-sets : 6500° K whitepoint default



Graphics Input : USB type C port (supporting DisplayPort Alternate Mode) or DisplayPort or HDMI 2.0 port (required for 3840 x 2160 resolution).



Multi-Touch : Yes



Pen : Wacom Pro Pen 2



Pressure Levels : 8192, both pen tip and eraser



Tilt Range : 60 degrees



Tilt Recognition : ±60 levels



Type : Pressure-sensitive, cordless, battery-free



Switches : Tip switch, 2 side switches, eraserNibs 10 (6 standard, 4 felt) in pen standPen Box/ Holder Yes - Pen HolderPen Stand YesGrip Latex-free silicone rubberTechnology Patented electromagnetic resonance methodResolution 5080 lpiExpressKeys™ 17 customizable, application-specific on included ExpressKey™ RemoteTouch Ring Yes - on included ExpressKey RemoteTouch Strips NoRocker Ring And Home Button Yes - on included ExpressKey RemoteRadial Menu YesPrecision Mode YesDisplay Toggle YesDedicated Pan, Scroll, Zoom, Brush Size YesExpressKey™ Remote Dimensions 135 x 52 x 10 mm (5.3 x 2.0 x 0.4 inch)ExpressKey™ Remote Continuous Operation Up to 160 hours, if a key is pressed every 30 secondsExpressKey™ Remote Charge Time Up to 2 hoursStand Adjustability Integrated pop-out legs for 20° angle (5° angle without legs)Stand Orientation Right or left-handed useCables Included USB to USB cable (3m), DisplayPort to DisplayPort cable (3m), HDMI 2.0 to HDMI2.0 cable (3m),USB-C to USB-C cable (1.8m), DisplayPort to Mini DisplayPort adapter, microUSB to USB cable (30 cm; for ExpressKey Remote), Power Cables (1.8m).PC and Mac Connection USB-C supporting DisplayPort Alternate Mode (DPAM), or DisplayPort and standard USB-A, or HDMI port and standard USB-A portPorts included 4 x USB3 ports*

1 x USB C port

1 x HDMI2.0 port

1 x DP port

2 USB-A Ports (one for ExpressKey Remote dongle)



*When connected to host computer over USB-C (including Cintiq Pro Engine), Cintiq Pro USB 3.0 ports run at USB 2.0 speeds to accommodate 4K video bandwidth over USB-C.Audio Audio headset jack, built-in microphonePower Supply Input 100 to 240 VAC, 50/60HzPower Supply Output 19.5V / 9.23APower Consumption Power ON mode (Max.): 129 W

Power sleep mode: 0.5 W or lower (Disconnect USB A or USB C cable)

Power OFF mode: 0.5 W or lowerBattery Rechargable Li-ion battery on included ExpressKey RemoteSecurity Kensington® Lock Port (lock purchased separately)



System Requirements PC: Windows® 7 or later (latest service pack/build), Mac: OS X 10.11 or later (latest update),

USB-C port with DisplayPort Alternate Mode (UHD), or Mini DisplayPort/DisplayPort (UHD) and USB-A, or HDMI 2.0 (UHD) and USB-A; Internet access for driver download.



What's Included : Wacom Cintiq Pro 32

Wacom Pro Pen 2 with 4-color pen ring set

ExpressKey™ Remote (with USB-A RF dongle and 30cm micro-USB to USB charger cable)

Pen stand with 10 replacement nibs (6 standard, 4 felt) and nib removal tool

Pen holder,

180W AC adaptor and 1.8m power cable

1.8m USB-C to USB-C cable,

Quick Start Guide

Regulation sheet

Cleaning cloth



Warranty : 1 year
